Ubiquiti US‑24:
Ubiquiti US‑24 - is 24-port managed gigabit switch with a wide set of security and resiliency.
Main features of Ubiquiti US‑24:
- Operation mode (switching, mirroring, or aggregate) per port
- Spanning tree configuration
- 802.1x control and RADIUS VLAN
Ubiquiti US‑24 Specifications:
| Option | Value |
|---|
| Total Non-Blocking Throughput | 70 Gbps |
| Switching Capacity | 140 Gbps |
| Forwarding Rate | 104.16 Mpps |
| Power Method | 110-120VAC / 210-230VAC |
| Networking Interfaces | (24) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1 Gbps SFP+ Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports |
| Management Interface | (1) 10/100 Ethernet Port |
| Dimensions | 443 x 43 x 286 mm |
| Weight | 3.56 kg |
